Measuring Heat Electronically: A Look at Various Sensory Approaches
Thermocouples, a staple in temperature sensing, convert temperature into a measurable electrical signal through the Seebeck effect — also known as the thermoelectric effect. This principle involves the generation of an electrical voltage when two dissimilar metals are connected together and exposed to a temperature difference.
The Principle of the Seebeck Effect
At the heart of the Seebeck effect lies the idea that when two dissimilar metals are joined at one end and kept at different temperatures, a voltage (electromotive force, or EMF) is generated at the junctions. This voltage is proportional to the temperature difference between the two junctions. The specific arrangement of metals used in thermocouples ensures that as the temperature changes at the measuring junction (the end exposed to the unknown temperature), the generated voltage also changes.
The Working Mechanism of Thermocouples
A thermocouple consists of two wires made from different metals or alloys that are joined at one end, known as the measuring junction or hot junction. The other ends are connected to a voltage reader, forming a circuit. When the two junctions are at different temperatures, a temperature gradient is established along the conductors. This gradient causes a change in the electron density of each metal, leading to the generation of an EMF. The voltage generated due to the temperature gradient is measured at the connection point (the cold junction), which is typically kept at a constant temperature (like 0°C) to serve as a reference. This setup allows the thermocouple to measure the differential temperature between the measuring point and the reference point.
To maintain accuracy, a cold junction compensation is necessary, as thermocouples measure the temperature difference between the hot and cold junctions. This ensures that changes in the ambient temperature at the cold junction do not affect the readings.
Applications and Advantages
Thermocouples are widely used in industrial applications due to their ability to measure high temperatures (up to 1700°C or more), their rapid response time, and their robustness. They are less expensive than some other temperature sensors like resistance thermometers and are suitable for harsh environments.
From non-contact thermometers and passive IR (PIR) sensors to various industrial applications, the combination of the Seebeck effect and the design of thermocouples allows for efficient conversion of temperature differences into electrical signals, making them versatile tools for temperature measurement in various fields.
This article is but a glimpse into the world of thermocouples. Future articles will delve deeper into other temperature sensors, such as vibrating wire sensors, thermistors, and smart sensors that use the I2C bus for data transmission. Stay tuned!
A wood thermometer is featured in the article's image.
Some thermocouples use different wire materials, such as type J (iron) and type T (copper).
Reading thermistors requires measuring resistance and fitting it to a curve to get the real temperature.
There are still lots of sensors left to talk about in future articles.
Smart sensors can use any of the methods discussed to measure temperature, convert it to engineering units, and send the data over an I2C bus.
Some Integrated Circuits (ICs) use the temperature-dependent bandgap voltage property for temperature sensing.
The CPU in a PC uses the same method to measure internal temperature for reporting and thermal management.
An approximate temperature can be obtained by counting the number of chirps made by crickets in 15 seconds and adding 37 degrees Fahrenheit.
